低转速发电机 无锡风机 3000w垂直轴风力发电机 出口 1个起批
Debs/Model | F-1000 | F-2000 | F-3000 |
Rated Power | 1000W | 2000W | 3000W |
maximum power | 2000W | 3000W | 4500W |
Rated voltage | 48/100V | 48/96V/220V | 96/120V/300V |
Start up wind speed | 2.5m/s | 2.5m/s | 2.5m/s |
Rated wind speed | 10m/s | 10m/s | 10m/s |
Security wind speed | 40m/s | 40m/s | 45m/s |
Net weight | 75kg | 90kg | 115kg |
Maple leaf height | 2.8m | 2.8m | 3.6m |
Package weight | 70 | 80 | 105 |
Blade number | 3pcs | ||
Blade material | nylon fiber | ||
body material | A3 | ||
Generator | Three-phase permanent magnet ac synchronousGenerator | ||
Control System | Electromagnet | ||
Yaw mode | 3,5KW Folding tail /10-20 Electronic yaw | ||
Insulation | Insulation | ||
Tower | Cable / Independent tower | ||
Working Temperature | -40℃-80℃ | ||
